description

Features

• User-friendly in-line programming - User can program the AEG at any moment by just using the trigger
• Programmable shot count from 3/6/9
• Programmable shoot mode "Auto Fire Mode"
• Equipped with battery-low protection
• Equipped with up-to-date power MOSFET technology
• Active braking technology employed
• Beep tones available for programming confirmation and battery low indication
• Self-adjust battery status to suit various types of batteries

Add "burst function" to virtually any Airsoft AEG in seconds! The BPM provides you reduced gearbox wear and tear, improved trigger control and tactical advantages! The BPM is the Ver.2 design of the Burst Wizard we previously offered with "easier adjustment", "mosfet technology" and "real time burst fire"!

The "BPM" is equipped with low-battery detection. There are 2 pre-installed thresholds at 6.3V and 9.3V allowing a wide range of battery voltage to be used. The device will detect the initial voltage when the battery is connected and determine which threshold to be used. Once the battery goes below the preset threshold, the device will generate a warning tone and stop the gun from firing during trigger pull. This is especially useful for LiPo battery applications due to the inherited trait of LiPo batteries where they should not to be drained completely.

Product Specifications

Connector Type: Small Tamiya
Size: 45mm x 17mm x 8mm
Operating Voltage: 7.2~12.0V
Maximum Continuous Current: 65 Amp
Recommended operating battery type: Li-po 2~3 cells. (7.4~12V)
Programmable "Burst" Mode: 3/6/9 shots
Programmable "continuous mode: Auto Fire Mode
Battery Low Detection: 6.6V ~ 9.9V
*If your AEG's ROF is higher than 25, there will be a inaccuracy of +1 shot. For example, 2 trigger pull adjustment for 3 round burst and so on.

ONLY use the following types of batteries with the Burst Wizard:

• NiMH: 7.2v (6 cells), 8.4v (7 cells), 10.8v (9 cells), 12v (10 cells)
• LiPo: 7.4v (2 cells), 11.1v (3 cells)
